Stage Plot: The Complete Guide for Tour Managers

Every venue has a stage manager waiting for your stage plot. Send one that's unclear, outdated, or missing half the information, and you've just made their job harder and your load-in slower. Send a clean, thorough stage plot ahead of time, and you walk into a venue where half the work is already done.

If you're new to touring, this guide will explain everything you need to know about stage plots: what they are, what goes on them, and how to create one. If you're already out on the road, skip to the sections on managing stage plots across a full tour and navigating festival changeovers — that's where most of the practical detail lives.

What Is a Stage Plot?

A stage plot is a diagram showing the exact placement of equipment, musicians, and technical gear on a performance stage. Tour managers and production managers use stage plots to communicate setup requirements to venue crews and local technicians before the show.

A thorough stage plot tells the venue crew where everything goes before anyone sets foot on stage, instruments, amplifiers, monitors, microphones, risers, power drops, and the position of each performer. Combined with an input list, it's the primary document your production team sends during the advance.

The goal is simple: get to soundcheck faster with fewer surprises.

What Goes on a Stage Plot?

The answer depends on the size of the tour. A four-piece indie band playing 300-cap rooms needs a different level of detail than a production touring arenas with eight trucks of gear.

For smaller tours and club shows, your stage plot should include:

- Position of each musician and their primary instrument
- Amplifier placement (and whether each amp has a balanced direct out)
- Microphone placement and stand type for each source
- Monitor wedge positions and who needs what in their mix
- DI box locations for any direct sources (keys, bass, acoustic guitars)
- Power drop locations
- Band name and production contact information
- Date the document was last updated

For mid-size and larger tours, add:

- Riser dimensions and positions
- Distances between band members
- Backline specifications (amp makes/models, cabinet configurations)
- In-ear monitor system details and who is on IEMs vs. wedges
- Stage dimensions or size requirements
- AC power requirements and voltage specifications
- Any fly-in or festival-specific requirements
- Notes for local techs who aren't familiar with your production

The more consistent your touring production, the more detail you can lock in. Most production team doesn't rebuild the stage plot for every city — they have a master document that gets updated when something changes, and the same document covers 87 venues on a world tour.

Stage Plot and Input List: What's the Difference?

They're related documents but serve different purposes. The stage plot is the visual diagram, it shows where everything is. The input list is the technical channel-by-channel breakdown — it shows what everything is.

The input list tells the sound engineer: channel 1 is kick drum, SM91 microphone; channel 2 is snare top, SM57, needs a gate; channel 3 is hi-hat, small-diaphragm condenser, no gate. The stage plot tells them where the drum kit is on the stage.

Both documents travel together as part of your tech rider, alongside the hospitality rider and any other advancing documents. Send them as a package whenever you're advancing a show.

Learn how Daysheets helps you stay organized through the advancing process →

How to Create a Stage Plot

You don't need design software or an art degree. You need accuracy.

Step 1: Map your stage setup

Start from scratch for each new tour configuration. Don't recycle last tour's stage plot unless the setup is genuinely identical. Decide where each person stands, where amps live, and where monitors go — then draw it.

Step 2: Orient it correctly

Stage plots are drawn from the audience's perspective, looking at the stage. Stage left is the performer's right as they face the audience.

Step 3: Use consistent symbols

You don't need custom icons. Standard shorthand works: circles for drums, rectangles for amps, triangles for monitor wedges, X-in-a-circle for microphones. If you're using professional stage plot software, icons are built in. The priority is clarity, not aesthetics.

Step 4: Add the technical details

Label every amp with its balanced output situation. Note which sources are going DI vs. mic. If a keyboard player has two rigs, both need to be on the plot. Mark power drop locations. Note any special requirements the local crew might not expect.

Step 5: Create the input list

Build the input list in parallel with the stage plot. Channel numbers should correspond between the two documents: if kick drum is channel 1 on the input list, the kick drum should be clearly labeled on the stage plot.

Step 6: Include contact information

Every stage plot should have the band or artist name, the name and phone number of whoever is advancing production, and a version date. When a venue coordinator is holding three different stage plots from three different versions of your tech rider, the date tells them which one to use.

Update the plot before it becomes a problem

The worst time to discover your stage plot is wrong is when the local sound engineer is staring at it confused at load-in. Review your tech rider at the start of each leg of the tour. If something changed in the last run of shows, update it before the next run starts.

Communicate changes to management and the booking agency

Outdated stage plots float around in the industry. A venue booker might have a stage plot from a year ago that's completely wrong. When you update your tech rider, send the new version to management and the agency so they're distributing the right document.

## Stage Plots at Festivals: A Different Challenge

Festival stage plots add pressure that club tours don't — mainly because your changeover window is short and the stakes for getting it wrong are high.

At a festival, the stage is shared. Your stage plot doesn't just tell crew where your gear goes; it helps the festival's production team plan the changeover logistics. They're working backward from your set time, figuring out what can be preset in the wings, what the previous act needs to clear, and where your monitors go relative to their monitor positions.

A few things matter more at festivals:

Send it early and follow up. Festival production schedules are built weeks in advance. Your stage plot and input list should be in their hands well before the show week..and you should confirm receipt.

Be specific about your requirements. Festivals often provide backline. If you need a specific drum configuration or amp type, it needs to be in writing. Don't assume.

Include your changeover requirements. How long do you need on stage before your set? What gets preset in the wings vs. set up on stage? The more you communicate, the smoother the changeover.

In a busy festival environment, an accurate stage plot can mean the difference between an easy changeover and an absolute “sufferfest."

Stage Plot Software: Your Options

You have choices across a wide range of budgets and complexity.

Google Draw

Free, accessible, and honestly sufficient for most smaller touring operations. It's not purpose-built for stage plots, but you can create something clear and shareable without spending anything. Drag-and-drop, easy to update, exports to PDF.

StagePlotPro and StagePlot Guru

Purpose-built standalone tools with dedicated stage plot icons, input list integration, and PDF export. Both work well. They're disconnected from your tour management workflow, which means updating your stage plot in one place and your tour details in another.

Daysheets Labs: Stageplot

Daysheets has launched an integrated stage plot builder that makes it simple to build your first set of documents for the tour. Completely free, easy to use, give the Daysheets Labs Stageplot a go!

Click here to try our Stage plot and input list builder!

Common Stage Plot Mistakes (and How to Avoid Them)

Sending an outdated document is the most common and most damaging mistake. Always check the version date before you advance a show.

Making your stage plot too complicated can be frustrating if the local crew has to study it for five minutes to understand it. Aim for clarity over completeness. The most important information: where people stand, where amps go, where power is needed; should be immediately obvious.

Omitting power drop locations. Venue crews need to know where you need power before anything else goes in place. Missing this detail delays setup.

Conclusion

The stage plot is one of the first things a venue production team sees from your tour. A clear, current, well-organized stage plot signals that the rest of your operation is run the same way. It makes load-in faster, soundcheck smoother, and the day easier for everyone involved.

Whether you're running your first club tour or managing a world tour with 80 venues, the principle is the same: accurate documents, sent early, kept current.
